CPE610 - CPE de Exterior de 5 GHz a 300Mbps, Antena direccional de 23dBi, potencia de 27 dBm, PoE pasivo

CPE610 - CPE de Exterior de 5 GHz a 300Mbps, Antena direccional de 23dBi, potencia de 27 dBm, PoE pasivo

$ 1,420.36 MXN
$ 1,420.36 MXN
Oferta Agotado

Tiempo de entrega 2 - 7 días hábiles

406 en existencias

CARACTERÍSTICAS DE HARDWARE

  • Procesador: Qualcomm 560MHz CPU, MIPS 74Kc
  • Memoria: 64MB DDR2 RAM, 8MB Flash
  • Interface: 1 10/100Mbps Shielded Ethernet Port (LAN/POE)
    1 Reset Button
  • Fuente de Alimentación: Passive Power over Ethernet via LAN (+4,5pins; -7,8pins)
    Voltage range: 16-27VDC
  • Dimensiones (W X D X H): 366 x 280 x 207 mm (14.4 x 11.0 x 8.1 in.)
  • Dimensiones: 360 x 280 x 207 mm (14.4 x 11.0 x 8.1 in.) (No mount)
  • Ganancia de Antena: 23dBi
  • Cobertura de Antena: 9°(Azimuth), 7°(Elevation)
  • Protección: 15KV ESD Protection
    6KV Lightning Protection
  • Cercado: Material: Outdoor PC stabilized plastic
    Weatherproof: IP65 water and dust proof design

CARACTERÍSTICAS INALÁMBRICAS

  • Estándares Inalámbricos: IEEE 802.11a/n
  • Protocolo Propietario: TDMA Mode (with Pharos MAXtream enabled)
  • Velocidades Inalámbricas: Up to 300Mbps (40MHz, Dynamic)
    Up to 144.4Mbps (20MHz, Dynamic)
    Up to 72.2Mbps (10MHz, Dynamic)
    Up to 36.1Mbps (5MHz, Dynamic)
  • Frecuencia: 5.15~5.85GHz
  • Potencia de Transmision: Max. 27dBm (Adjustable power by 1dBm)

CARACTERÍSTICAS DE SOFTWARE

  • Configuracion De Red: WAN: Static/Dynamic/PPPoE/L2TP/PPTP
    LAN: Static/Dynamic/DHCP
    Forwarding: ALG/UPnP/Virtual Server/Port Trigger
    Security: SPI Firewall/ Ping Forbidden/DoS Protection
    Access Control
    Static Routing
    Bandwidth Control
    IP & MAC Binding
  • Configuraciones Inalámbricas: Pharos MAXtream TDMA Technology
    Selectable Channel Width: 5/10/20/40MHz
    Auto Channel Selection
    Transmit Power Control
    Dynamic Frequency Selection(DFS)
    WDS Enable/Disable
    Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption,
    64/128/152-bit WEP Encryption
    SSID Broadcast Enable/Disable
    Multi-SSID with VLAN Tagging(AP Mode only)
    Distance/ACK Timeout Setting
    Wireless MAC Address Filter
    Wireless Advanced:
    Beacon Interval/RTS Threshold/Fragmentation Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia
  • Administración: Discovery and Remote Management via Pharos Control application
    HTTP/HTTPS Web-based management
    System log
    SNMP Agent(v2c)
    Ping Watch Dog
    Dynamic DDNS
    SSH Server
  • Herramientas de sistema: Indicators: Signal Strength/Noise/Transmit CCQ/CPU/Memory
    Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP
    Spectrum Analyzer
    Speed Test
    Ping
    Traceroute
  • Optimizaciones a Nivel de Sistema: Optimized IGMP Snooping/Proxy for multicast applications
    Hardware watch dog

POE ADAPTER FEATURES

  • Dimensions(W x D x H): 85.8×43.9×29.7 mm
  • Interfaces: 1 AC Jack with Earth Ground
    1 10/100Mbps Shielded Ethernet Port (Power + Data)
    1 10/100Mbps Shielded Ethernet Port (Data)
  • Botón: Remote Reset Button
  • Power Status LEDs: Green
  • Input: 100-240VAC, 50/60Hz
  • Output: 24VDC, 0.5A Max
    +4, 5pins; -7, 8pins. (Support up to 60m Power over Ethernet)
  • Eficiencia: >84.29%
  • Certifications: CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark

OTROS

  • Certificacion: CE, FCC, RoHS, IP65
  • Contenidos del Paquete: Outdoor Wireless CPE
    24V 0.5A Passive PoE Adapter
    Pole Mounting Straps
    AC Power Cord
    Installation Guide
  • Requisitos del Sistema: Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux.
    Note: We recommend you to use one of following Web browsers for an improved user experience: Google Chrome, Safari, and Firefox. IE browsers are not recommended.
  • Ambiente: Operating Temperature: -40°C~70°C (-40°F~158°F)
    Storage Temperature: -40°C~70°C (-40°F~158°F)
    Operating Humidity: 10%~90% non-condensing
    Storage Humidity: 5%~95% non-condensing
